Meeting the Hot Water Heating Demands for Hospitals

How do you provide 24/7, high-volume hot water to a facility that never sleeps? For hospitals, the answer is becoming increasingly difficult. Hot water is needed throughout these facilities – from patient restrooms to more critical uses such as infection control, sterilization, and high-volume laundry services.  But traditional hot water solutions are struggling to keep up. Today, we’ll look deeper into these challenges and how they can be met.

Traditional Tank-Based Solutions

Hospitals have historically relied on massive storage tanks for their hot water needs. Tank-based systems have been recognized for their ability to consistently deliver hot water while drawing energy slowly. But these benefits have become overshadowed by significant operational drawbacks:

First, they take up a lot of space. Modern medical equipment has become larger and takes up more of the hospital’s footprint. A lot of hospitals were built decades ago, when equipment was smaller or nonexistent, updates to their infrastructure require significant space. The answer is simple: floorspace is a precious commodity.

Another major drawback comes to light when older storage tanks fail. They are often walled in, which turns removal and replacement into an unwanted capital project. Structural walls may need to be knocked down. Rigging usually needs to be brought in. This all adds up to prolonged downtime and expensive replacement costs.

One other issue is that conventional systems can’t always meet the continuously fluctuating demands that hospitals face. Their design and space requirements simply do not lend themselves to scalability.

Today’s Alternative

Today, hospitals have a viable alternative: compact, semi-instantaneous heaters. Their adaptable design provides the much-needed balance between efficient space usage and the ability to heat water on demand.

Semi-instantaneous water heaters work by circulating water through a compact heat exchanger which rapidly transfers heat to a small volume of water. Unlike a traditional tank that sits idle, this approach uses high-speed valves to modulate energy input in real time. This allows them to maintain precise temperature, while only keeping a minimal amount of water in reserve.

Benefits of Semi-Instantaneous Heaters

Healthcare facilities benefit by using these compact heaters in many ways, including:

• Scalability and Redundancy – hospitals experience extreme peak demands. Instantaneous water heaters, such as our Mink Packs, can be racked horizontally or stacked vertically. A multi-unit setup can be configured for a lead-lag capability. Here, one unit is the primary, that runs at full scale throughout the day. Then the back unit(s) can kick in automatically when hot water demands increase beyond their capacity. This setup also provides redundancy. If one unit requires maintenance, the other(s) will be there to back it up. This ensures that hot water will continue to flow uninterrupted.
• Retrofit Versatility – older hospitals with conventional systems don’t need to call in the demolition crew to take advantage of this technology. These units are compact and fit through standard doorways. While most installations use electronic controls, they can also be configured to accommodate existing pneumatic systems.
• Improved Energy Efficiency – semi-instantaneous water heaters use orifice traps that build pressure and push the condensate out without losing heat. This improves efficiency, since the BTUs transfer to the water, and are not lost to surrounding air.
• Lower Maintenance – these reliable heaters have more advanced parts when compared to conventional tank-based systems. They require much less maintenance to operate, freeing up the maintenance department’s time to resolve other items on their daily punch list.

Conclusion

The demands of today’s healthcare facilities outweigh what conventional tank-based systems can provide. Semi-instantaneous water heaters are a compact, efficient alternative that can meet or exceed today’s needs, and continue to do so as demands grow overtime.

Need a reliable alternative to conventional tank-based heaters? Our Mini-Pack Semi-Instantaneous heaters are ideal for retrofits and new installations. They are dependable, quiet, offer outstanding thermal efficiency, and take up little floor space. Reach out to us today for more information or a quote.
