Mini-Pack Semi Instantaneous Potable Water Heaters

Precise temperature control and thermal efficiency in a compact water heater package. Constructed with rust-free austenitic stainless steel and copper for potable hot water. Engineered for commercial and institutional buildings.

APPLICATIONS

Hospitals, correctional facilities, office buildings,
university dormitories, military bases

SPEAK TO AN EXPERT

Features

- Single or double-wall copper tubing construction
- Completely packaged, ready for hook-up
- All solid non-ferrous construction on potable water side. Solid austenitic stainless steel shell with copper tubes
- Vertical or horizontal models available
- Tube bundle readily accessible without moving heater, shell or foundation (excluding double-wall vertical model)
- Compact design requires less floor space
- Mirror finish stainless steel jacket
- Self-operated, pneumatic or electric control valves are available.
- All trim items such as steam traps, isolating valves, gauges, etc.

Options

- Custom package available
- Cupro Nickel or Stainless Steel tubing
- Vented double-wall tubing, as required for cross-contamination prevention by the National Plumbing Code, is now mandatory in several states and cities. The ACE double-wall mini-pack is a proven, practical way to comply with double-wall regulations.
- Extended 10 and 20 year warranties
- Nema 4 control boxes
- Double safety solenoid

Performance

- Close temperature control ± 4°F at heater outlet
- Models accept boiler water, steam from 15 through 150 psig or high temperature hot water as heating medium
- Steam models provide condensate sub-cooling
- Standard sizes cover hot water output from 1 to 300 GPM simplifying size.
- Constructed and stamped to ASME BPV Code Section VIII
